HEX7 Series

HEX7 TOPCon N Type 600W Bifacial Solar Panel

Bluesun TOPCon N-Type Solar Panel 600W Bifacial Half Cell Solar Panel For Business

  • Model:

    BSM600M10-72HNH
  • Solar Cell:

    N-type Topcon
  • Number Of Cells:

    144 (6*24)
  • Power Range:

    580-600W
  • Size:

    2278*1134*30MM
  • Certificate:

    CE/TUV/UL/CEC
  • Lead Time:

    15 Days
  • Payment:

    T/T, L/C,Western Union
  • Warranty:

    30 Years

Bluesun Topcon Solar Panels
*Higher power

For the same module type, the power of N-type modules is 15~20W higher than that of P-type modules.

*Higher Bifaciality

For the same module type, the bifaciality of the N-type module is increased by 10~15% compared with the P-type module.

*Lower Temperature Coefficient

The temperature coefficient of the P-type module is -0.34%/℃ The temperature coefficient of the N-type module is optimized to -0.30%/℃. Power generation is particularly prominent in high-temperature environments
*Better Output Warranty

1st year <1%(P-type 2%). 30-year warranty for both monofacial and bifacial poweroutput (30 years for P-type bifacial and 25 years for P-typemonofacial). Output power is no less than 87.4% of the initial after 30years.



SPECIFICATIONS

Module Type

BSM580M10-72HNH

BSM585M10-72HNH

BSM590M10-72HNH

BSM595M10-72HNH

BSM600M10-72HNH



STC

NMOT

STC

NMOT

STC

NMOT

STC

NMOT

STC

NMOT

Maximum Power (Pmax/W)

580

436.2

585

440

590

444

595

448

600

452

Operating Voltage (VmpM

43.28

40.05

43.48

40.1

43.68

40.15

43.88

40.2

44.08

40.25

Operating Current (lmp/A)

13.41

10.86

13.47

10.94

13.53

10.86

13.59

11.1

13.65

11.18

Open-Circuit Voltage (Voc/ V)

51.64

49.05

51.84

49.24

52.04

49.05

52.24

49.62

52.44

49.81

Short-Circuit Current (lsc/A)

14.29

11.6

14.33

11.64

14.37

11.6

14.41

11.72

14.45

11.76

Module Efficiency(%)

22.5

22.7

22.8

23

23.2

STC: Iradiance 1000W/m²,Cell Temperature 25°C, Air Mass AM1.5

NMOT: Irradiance at 800W/㎡, Ambient Temperature 20°C, Air Mass AM1.5, Wind Speed 1m/s

Bluesun Solar PV modules have been certifited by UL, TUV, CE, IEC, CEC, MCS, etc.
